Sigma, KQL, and SPL Examples
Purpose
Show how to express detection logic across platforms while marking each example honestly with its DRL level and validation requirements.
Core Rule
Platform syntax is implementation detail. The analytic logic must exist first: behavior, telemetry, fields, false positives, and validation. Every example below is a DRL-4 candidate — draft logic only. None are production-ready without positive test, negative test, benign baseline, historical replay, SOC pilot, and production approval.
How to Read These Examples
Each example includes:
- Behavior: What the detection targets.
- Source behavior: CTI claim that justifies the detection.
- DRL: Current readiness level.
- False positives: Known benign matches.
- Validation required: What must happen before promotion.
Example 1: Script Interpreter Spawned from Archive Extraction
Behavior: A compressed archive is extracted and immediately spawns a scripting engine. This is a common pattern for phishing payload delivery.
Source behavior: Reported — multiple vendor reports describe archive-attached phishing leading to PowerShell, wscript, or cscript execution. No local telemetry confirmation.
DRL: 4 — draft logic, no test evidence.
False positives: Admin deployment packages, software installers with embedded scripts, developer tooling.
Validation required: Positive synthetic test (simulate archive + script spawning), negative test (confirm legitimate installer does not fire), benign baseline review, historical replay.
Sigma (DRL-4 candidate — not production)
title: Archive Extraction Followed by Script Interpreter — DRL-4 Candidate
status: experimental
description: >
Detects a scripting engine (PowerShell, wscript, cscript, mshta) spawned as a child
of a known archive extraction utility. DRL-4 draft only. Requires positive/negative
testing, benign baseline review, and SOC pilot before promotion.
references:
- https://attack.mitre.org/techniques/T1059/001/
author: CTI Analyst Field Manual
date: 2026-05-16
tags:
- attack.execution
- attack.t1059.001
- drl.4.candidate
logsource:
category: process_creation
product: windows
detection:
selection_parent:
ParentImage|endswith:
- '\7z.exe'
- '\WinRAR.exe'
- '\msiexec.exe'
- '\expand.exe'
selection_child:
Image|endswith:
- '\powershell.exe'
- '\pwsh.exe'
- '\wscript.exe'
- '\cscript.exe'
- '\mshta.exe'
condition: selection_parent and selection_child
falsepositives:
- Software installation packages that extract and execute setup scripts
- Admin automation tools using archive-based deployment
- Developer tooling
level: medium
KQL — Microsoft Defender for Endpoint (DRL-4 candidate — not production)
// DRL-4 candidate — not production
// Requires telemetry validation: confirm ParentProcessName is populated
// Validate positive/negative cases before enabling as alert
DeviceProcessEvents
| where Timestamp > ago(7d)
| where InitiatingProcessFileName in~ ("7z.exe", "WinRAR.exe", "msiexec.exe", "expand.exe")
| where FileName in~ ("powershell.exe", "pwsh.exe", "wscript.exe", "cscript.exe", "mshta.exe")
| project Timestamp, DeviceName, AccountName,
InitiatingProcessFileName, InitiatingProcessCommandLine,
FileName, ProcessCommandLine, FolderPath
| order by Timestamp desc
SPL — Splunk with Sysmon (DRL-4 candidate — not production)
`sysmon` EventCode=1
(ParentImage="*\\7z.exe" OR ParentImage="*\\WinRAR.exe" OR ParentImage="*\\msiexec.exe")
(Image="*\\powershell.exe" OR Image="*\\wscript.exe" OR Image="*\\cscript.exe" OR Image="*\\mshta.exe")
| table _time, host, User, ParentImage, ParentCommandLine, Image, CommandLine
| sort -_time
Example 2: Non-Browser Process Outbound on IMAPS / SMTPS
Behavior: A non-browser, non-mail-client process opens an outbound connection on TCP 993 (IMAPS) or TCP 465/587 (SMTPS). This is a C2 exfiltration pattern that abuses email protocols.
Source behavior: Reported — public CTI describes email-protocol C2 used by several threat clusters for data staging. Evidence label: Reported. Confidence: Medium (multi-vendor, no local telemetry confirmation).
DRL: 4 — draft logic, no test evidence.
False positives: Mail clients, backup tools, developer SMTP testing, monitoring agents.
Validation required: Positive test with netcat or mail client connecting on 993/465, negative test confirming Outlook or Thunderbird does not fire, baseline review of legitimate mail clients.
Sigma (DRL-4 candidate — not production)
title: Non-Browser Process Outbound IMAPS or SMTPS — DRL-4 Candidate
status: experimental
description: >
Detects a process connecting outbound on IMAPS (993) or SMTPS (465, 587) that is
not a known mail client or browser. C2 via email protocol. DRL-4 draft only.
references:
- https://attack.mitre.org/techniques/T1071/003/
author: CTI Analyst Field Manual
date: 2026-05-16
tags:
- attack.command_and_control
- attack.t1071.003
- drl.4.candidate
logsource:
category: network_connection
product: windows
service: sysmon
detection:
selection:
EventID: 3
DestinationPort:
- 993
- 465
- 587
filter_legit:
Image|endswith:
- '\OUTLOOK.EXE'
- '\thunderbird.exe'
- '\chrome.exe'
- '\firefox.exe'
- '\msedge.exe'
condition: selection and not filter_legit
falsepositives:
- Mail clients not in filter list
- Backup and archiving tools with SMTP reporting
- Developer SMTP testing utilities
level: medium
KQL — Microsoft Defender for Endpoint (DRL-4 candidate — not production)
// DRL-4 candidate — not production
// Add known-good mail clients to exclusion list after baseline review
let LegitMailClients = dynamic(["outlook.exe","thunderbird.exe","chrome.exe","firefox.exe","msedge.exe"]);
DeviceNetworkEvents
| where Timestamp > ago(7d)
| where RemotePort in (993, 465, 587)
| where tolower(InitiatingProcessFileName) !in (LegitMailClients)
| project Timestamp, DeviceName, AccountName,
InitiatingProcessFileName, InitiatingProcessCommandLine,
RemoteIP, RemotePort
| order by Timestamp desc
SPL — Splunk with Sysmon (DRL-4 candidate — not production)
`sysmon` EventCode=3
(DestinationPort=993 OR DestinationPort=465 OR DestinationPort=587)
NOT (Image="*\\OUTLOOK.EXE" OR Image="*\\thunderbird.exe" OR Image="*\\chrome.exe"
OR Image="*\\firefox.exe" OR Image="*\\msedge.exe")
| table _time, host, User, Image, CommandLine, DestinationIp, DestinationPort
| sort -_time
DRL Promotion Checklist for Any Example Above
Before any example can move from DRL-4 to DRL-5 or higher, the following must be documented:
| Gate | Required Evidence |
|---|---|
| DRL-5 | Positive synthetic test fires; obvious benign control does not fire. |
| DRL-6 | Benign baseline reviewed; expected false-positive classes documented. |
| DRL-7 | 30-day historical replay; alert volume and false-positive rate measured. |
| DRL-8 | SOC triage playbook, owner, escalation path, and rollback plan complete. |
| DRL-9 | Production approval with change record and residual risk acceptance. |
No example on this page has passed DRL-5. None may be deployed as a production alert.
Common Mistakes
- Jumping from actor report to production alert by skipping telemetry validation.
- Using these examples as production rules because they have correct syntax.
- Failing to add environment-specific exclusions to the filter lists.
- Omitting false-positive review before enabling alerts.
- Claiming detection coverage because a technique is mapped.
Analyst Checklist
- Is there a source-backed behavior?
- Is telemetry confirmed available in the target environment?
- Is the hypothesis falsifiable?
- Are false positives named from real operational context?
- Is readiness level honestly stated as DRL-4?
Output Artifact
Detection ID:
Behavior:
Source Claim:
Evidence Label:
Sigma Path:
KQL Variant:
SPL Variant:
Positive Test Result:
Negative Test Result:
Benign Baseline Status:
Historical Replay Status:
DRL:
Owner:
