AI-Assisted ADCS ESC8 Lab Validation in GOAD-Mini

Controlled lab validation in a GOAD-Mini environment

AI-Assisted ADCS ESC8 Lab Validation in GOAD-Mini​

Controlled ADCS ESC8 validation with Cursor and HexStrike MCP​

Cursor HexStrike fully automated ADCS ESC8 attack — Controlled ADCS ESC8 validation with Cursor and HexStrike MCP

Abstract​

This article documents a controlled lab engagement that validates ADCS ESC8 exposure in GOAD-Mini. Starting from an IP address, the AI-assisted workflow helped sequence reconnaissance, ADCS enumeration, certificate-abuse validation, evidence collection, and remediation notes.

Lab result: In this GOAD-Mini run, a single high-level prompt initiated a multi-phase workflow. The outcome demonstrates orchestration capability in a controlled environment, not guaranteed autonomous reliability in production.

Known Limitations​

caution

This is a GOAD-Mini lab observation. It depends on intentionally vulnerable ADCS configuration, lab credentials, tool versions, and operator approval. Credential values and hashes are redacted in this public version.

If you like this research, buy me a coffee (PayPal) — Keep the lab running​

Introduction​

Traditional penetration testing requires careful operator control at each step: running tools, interpreting results, making decisions, and troubleshooting failures. This article demonstrates AI-assisted orchestration from a single prompt for a controlled ADCS ESC8 validation sequence in a lab environment.

What Makes This Attack Complicated?​

  1. Multi-Stage Attack Chain: 7 distinct phases, each with dependencies
  2. Blackbox Approach: Starting with zero knowledge (only IP address)
  3. Troubleshooting Support: Helps diagnose errors and propose alternatives
  4. Tool Orchestration: Coordinates multiple security tools seamlessly
  5. Contextual Sequencing: AI selects the next tool based on prior output

Attack Overview​

Target Environment​

  • Target IP: 192.168.56.10
  • Environment: GOAD-Mini (Game of Active Directory)
  • Starting Point: IP address only (blackbox)
  • End Goal: Validate ESC8 impact and document remediation evidence

Attack Chain​

IP Address (192.168.56.10)
    ↓
[Phase 1] Reconnaissance
    ├─ Port Scanning
    ├─ Service Enumeration
    ├─ Domain Discovery
    └─ ADCS Detection
    ↓
[Phase 2] Credential Acquisition
    ├─ Password Spraying
    ├─ ASREPRoasting
    └─ Kerberoasting
    ↓
[Phase 3] ADCS Enumeration
    ├─ CA Discovery
    ├─ Template Enumeration
    └─ Vulnerability Verification
    ↓
[Phase 4] Certificate Request
    ├─ Authenticate with Low-Privilege Creds
    ├─ Request Administrator Certificate
    └─ Save redacted certificate artifact
    ↓
[Phase 5] Certificate Authentication
    ├─ Use Certificate for PKINIT
    ├─ Obtain Kerberos TGT
    └─ Extract NTLM Hash
    ↓
[Phase 6] Impact Validation
    ├─ DCSync Attack
    ├─ Confirm DCSync risk in the lab
    └─ Redact sensitive hash material
    ↓
[Phase 7] Reporting
    ├─ Generate Comprehensive Report
    ├─ Document All Artifacts
    └─ Create Proof of Compromise

Single-Prompt Initiation​

The Prompt​

Perform a blackbox penetration test starting from IP address 192.168.56.10.
Validate ADCS ESC8 exposure in the GOAD-Mini lab. Use HexStrike MCP
tools for approved enumeration, evidence collection, and troubleshooting support.

Why This Works​

  1. Comprehensive Instructions: The prompt contains all phases, objectives, and troubleshooting steps
  2. Tool Integration: Leverages HexStrike MCP tools for seamless tool execution
  3. Error Handling: Includes automatic troubleshooting for common failures
  4. Adaptive Execution: AI can make decisions based on intermediate results

Phase-by-Phase Execution​

Phase 1: Reconnaissance​

Objective: Discover the target environment with zero prior knowledge.

Tools Used:

  • nmap_advanced_scan - Comprehensive port scanning
  • rustscan_fast_scan - Quick port discovery
  • enum4linux_scan - SMB enumeration
  • smbmap_scan - Share enumeration
  • nbtscan_netbios - NetBIOS name discovery
  • httpx_probe - HTTP service detection

Key Discoveries:

  • Domain: sevenkingdoms.local
  • NetBIOS: SEVENKINGDOMS
  • DC Hostname: kingslanding.sevenkingdoms.local
  • ADCS Web Enrollment: http://192.168.56.10/certsrv/ (HTTP - vulnerable!)

Automation Features:

  • Automatically identifies Windows Domain Controller
  • Extracts domain information from enumeration results
  • Detects ADCS Web Enrollment endpoint

Phase 2: Credential Acquisition​

Objective: Obtain low-privilege domain credentials.

Tools Used:

  • hydra_attack - Password spraying
  • netexec_scan - Credential validation

Attack Strategy:

  1. Extract usernames from Phase 1 enumeration
  2. Attempt password spraying with common passwords
  3. Use the approved lab credential test set

Results:

  • Credentials Obtained: TestUser:<redacted>
  • Access Level: Low-privilege domain user

Automation Features:

  • Runs only the approved lab credential checks
  • Validates credentials before proceeding
  • Documents credential exposure with sensitive values redacted

Phase 3: ADCS Enumeration​

Objective: Enumerate ADCS configuration and identify vulnerabilities.

Tools Used:

  • dirsearch_scan - ADCS endpoint discovery
  • execute_python_script - Certipy enumeration

Enumeration Commands:

 certipy find -u TestUser@sevenkingdoms.local -p '<redacted>' \
  -dc-ip 192.168.56.10

Key Findings:

  • CA Name: SEVENKINGDOMS-CA
  • Vulnerable Templates: ESC1, ESC8
  • ESC8 Confirmed: HTTP Web Enrollment accessible
  • Template Count: 34 templates discovered

Automation Features:

  • Automatically parses certipy output
  • Identifies vulnerable templates
  • Verifies ESC8 vulnerability exists

Phase 4: Certificate Request​

Objective: Obtain certificate for Administrator account.

Tools Used:

  • execute_python_script - Certipy certificate request

Command pattern:

 certipy req -u TestUser@sevenkingdoms.local -p '<redacted>' \
  -target http://192.168.56.10 \
  -ca SEVENKINGDOMS-CA \
  -template ESC1 \
  -upn Administrator@sevenkingdoms.local \
  -out <redacted-certificate-artifact>

Results:

  • Certificate Obtained: <redacted-certificate-artifact>
  • Status: ✓ Success
  • Template Used: ESC1 (vulnerable template)

Automation Features:

  • Automatically selects vulnerable template
  • Handles certificate request errors
  • Verifies certificate file creation

Phase 5: Certificate Authentication​

Objective: Use certificate for Kerberos authentication.

Tools Used:

  • execute_python_script - Certipy authentication

Command pattern:

 certipy auth -pfx <redacted-certificate-artifact> -dc-ip 192.168.56.10

Results:

  • Kerberos TGT: <redacted-cache-artifact> (obtained)
  • NTLM Hash: <redacted> (extraction confirmed in lab)
  • Status: ✓ Authentication successful

Automation Features:

  • Automatically uses certificate for PKINIT
  • Confirms NTLM hash extraction risk
  • Saves a redacted credential-cache artifact for the next approved phase

Phase 6: Impact Validation (DCSync Risk)​

Objective: Validate DCSync impact and document the exposure with sensitive values redacted.

Tools Used:

  • execute_python_script - Impacket secretsdump

Command pattern:

 export KRB5CCNAME=<redacted-cache-artifact>
secretsdump.py -k -no-pass Administrator@sevenkingdoms.local@192.168.56.10

Results:

  • Total Hashes Extracted: 27 user accounts
  • krbtgt Hash: Extraction confirmed and redacted (enables Golden Ticket attacks)
  • DCSync Risk: Confirmed in the lab

Sample Hashes:

 Administrator:500:<redacted>:<redacted>:::
krbtgt:502:<redacted>:<redacted>:::
TestUser:1001:<redacted>:<redacted>:::

Automation Features:

  • Automatically sets Kerberos environment variables
  • Performs DCSync attack
  • Confirms hash extraction impact
  • Redacts sensitive hash material from public documentation

Phase 7: Reporting​

Objective: Generate comprehensive report with all artifacts.

Tools Used:

  • create_file - Report generation

Report Contents:

  1. Executive Summary
  2. Phase-by-phase execution details
  3. All discovered information
  4. Vulnerabilities found
  5. Redacted credential-exposure evidence
  6. Proof of validated impact
  7. All approved artifacts (certificates, redacted hash evidence, logs)

Artifacts Generated:

  • <redacted-certificate-artifact> - certificate proof artifact
  • <redacted-cache-artifact> - Kerberos cache proof artifact
  • <redacted-hash-evidence> - redacted NTLM hash evidence
  • <redacted-dcsync-evidence> - redacted domain hash evidence
  • <report-artifact> - comprehensive report
  • <execution-log> - execution log with sensitive values removed

Automation Features​

1. Automatic Troubleshooting​

The framework handles common errors automatically:

  • Port Scan Fails: Tries alternative scan methods
  • SMB Enumeration Fails: Attempts with different credentials
  • Certificate Request Fails: Tries alternative templates
  • Authentication Fails: Retries with different methods
  • DCSync Fails: Verifies Kerberos and retries

2. Intelligent Decision Making​

The AI makes decisions based on results:

  • Domain Discovery: Automatically extracts domain from enumeration
  • Template Selection: Chooses vulnerable templates automatically
  • Credential Validation: Tests credentials before using them
  • Error Recovery: Adapts strategy based on failures

3. Comprehensive Logging​

Every action is logged:

  • Tool execution commands
  • Outputs and results
  • Errors and troubleshooting steps
  • Decision points and rationale

Results Summary​

Attack Timeline​

Key Achievements​

  • ✅ Zero Knowledge Start: Began with only IP address
  • ✅ High-Impact ADCS Exposure Validated: DCSync risk confirmed; sensitive hashes redacted
  • ✅ krbtgt Hash Exposure: confirmed and redacted
  • ✅ AI-Assisted Orchestration: single prompt initiated a reviewed workflow
  • ✅ Comprehensive Reporting: Full documentation generated

Technical Deep Dive​

Why This Attack is Complicated​

  1. Multi-Tool Orchestration: Coordinates 10+ different security tools
  2. Dependency Management: Each phase depends on previous results
  3. Error Handling: Automatically recovers from failures
  4. Data Parsing: Extracts structured data from unstructured outputs
  5. Decision Logic: Makes intelligent choices based on context

Attack Complexity Metrics​

  • Tools Used: 15+
  • Phases: 7
  • Decision Points: 20+
  • Error Scenarios Handled: 10+
  • Artifacts Generated: 10+

Defense and Mitigation​

Immediate Actions​

  1. Disable HTTP Web Enrollment: Force HTTPS only
  2. Enable SMB Signing: Prevent NTLM relay
  3. Restrict Certificate Templates: Remove vulnerable templates
  4. Monitor Certificate Requests: Alert on suspicious requests
  5. Implement Certificate Pinning: Prevent certificate abuse

Long-Term Security​

  1. Regular ADCS Audits: Review template permissions
  2. Network Segmentation: Isolate ADCS servers
  3. Privileged Access Management: Limit certificate enrollment
  4. Security Monitoring: Detect ESC8 attack patterns
  5. Staff Training: Educate on ADCS security

Detection and Monitoring​

Indicators of Compromise (IOCs)​

  1. Certificate Requests:
  • Unusual certificate requests for privileged accounts
  • Certificate requests from non-standard IPs
  • Multiple certificate requests in short time

2. Authentication Patterns:

  • PKINIT authentication from unexpected sources
  • Certificate-based authentication anomalies
  • DCSync attempts from non-DC systems

3. Network Traffic:

  • NTLM relay to ADCS HTTP endpoints
  • Unusual SMB authentication patterns
  • Certificate enrollment over HTTP

Detection Queries​

Windows Event Log:

 Event ID 4886 - Certificate Request
Event ID 4887 - Certificate Request Disposition
Event ID 4624 - Successful Logon (PKINIT)
Event ID 4662 - DCSync Operation

SIEM Queries:

  • Certificate requests for Administrator account
  • HTTP requests to /certsrv/ from non-DC IPs
  • NTLM authentication to ADCS endpoints

Conclusion​

This lab-observed ADCS ESC8 attack demonstrates:

  1. The Power of AI-Driven Pentesting: Single prompt achieves complete attack chain
  2. The Severity of ESC8: one misconfiguration can enable domain-level impact
  3. The Need for Automation: Manual testing cannot match AI speed and consistency
  4. The Importance of Defense: Proper ADCS configuration is critical

Key Takeaways​

  • ✅ ESC8 is Critical: HTTP Web Enrollment is a severe vulnerability
  • ✅ Orchestration Works: AI can sequence complex attack chains in a prepared lab environment
  • ✅ Defense is Possible: Proper configuration prevents this attack
  • ✅ Monitoring is Essential: Detect and respond to certificate-based attacks

References​

Andrey Pautov

If you like this research, buy me a coffee (PayPal) — Keep the lab running​

Known Limitations​

caution
  • Results are specific to the lab configuration used; outcomes will differ on hardened or patched targets.
  • AI tool selection is heuristic — novel service configurations may require re-prompting or manual follow-up.
  • All walkthroughs ran in an isolated VirtualBox/VMware network, not a production environment.
  • Timing and success rates vary with host CPU, RAM, and network latency.
  • Some tool outputs are truncated in the screenshots; full output was reviewed live during the session.

By Andrey Pautov on January 29, 2026.

Canonical link

Exported from Medium on May 15, 2026.
